HK Audio PR:O 210 SUB A User Manual

PREMIUM PR:O 1.0
8
4 Troubleshooting
The Limiter/Status LED does not light up when the power switched
on.
• Check if the power cord is plugged into the Mains input.
• Check if the mains power supply is providing current.
The Limiter/Status LED lights up red, flashing intermittently.
• The Limiter has actuated; lower the input level if necessary.
The Limiter/Status LED lights up red continuously, but no sound is
issuing from the cabinet.
• The enclosure’s protective circuit has tripped. Please contact your dealer.
The rendered music sounds distorted.
• Check your mixing console’s LED meters. They should not be constantly in
the red. If necessary, back o the volume at the mixer.
• If the LED displays on your mixer are in the green, back o the PREMIUM
PR:O active cabinet’s Gain knob.
• Observe the Limiter/Staus LED on the PREMIUM PR:O active enclosure’s
control panel. These may light up red, but only intermittently. The red
light may not illuminate continuously. If it does, turn down the Gain knob.
5 Applications
Go to page 18-21 for illustrations of cable connections.
6 Technical Specifications
Model PR:O 10 XD PR:O 12 D
PR:O 12 XD PR:O 15 D PR:O 15 XD PR:O 18 SUB A PR:O 210 SUB A
Max SPL 122 dB half space* 124 dB half space*
124 dB half space* 125 dB half space* 125 dB half space* 125 dB half space* 123 dB half space*
Max SPL peak 131 dB half space* 132 dB half space*
132 dB half space* 130 dB half space* 130 dB half space* 127 dB half space* 126 dB half space*
Max SPL calculated 133 dB half space 133 dB half space
133 dB half space 133 dB half space 133 dB half space 127 dB half space 126 dB half space
Frequency response
+/- 3 dB
81 Hz – 16 kHz 72 Hz – 16 kHz
80 Hz – 16 kHz 60 Hz – 16 kHz 61 Hz – 16 kHz 48 Hz – X-over 60 Hz – 150 Hz
Frequency response
-10 dB
69 Hz – 18 kHz 62 Hz – 18 kHz
69 Hz – 18 kHz 54 Hz – 18 kHz 57 Hz – 18 kHz 38 Hz – X-over 40 Hz – 150 Hz
Output power 1200 W 1200 W
1200 W 1200 W 1200 W 600 W 600 W
Amp type Class D - biamped Class D - biamped
Class D - biamped Class D - biamped Class D - biamped Class D Class D
Active protective
circuits
Peak and RMS Sound
Limiter (separate for HF
and LMF)
Peak and RMS Sound
Limiter (separate for HF
and LMF)
Peak and RMS Sound
Limiter (separate for HF
and LMF)
Peak and RMS Sound
Limiter (separate for HF
and LMF)
Peak and RMS Sound
Limiter (separate for HF
and LMF)
Subsonic Filter, Peak
Limiter
Subsonic Filter, Peak
Limiter
Bass woofer
1x 18" 2x 10"
Low/Mid speaker 1x 10" 1x 12"
1x 12" 1x 15" 1x 15"
HF driver 1" 1"
1" 1" 1"
Horn directivity 90° x 55° CD horn 90° x 55° CD horn
90° x 55° CD horn 90° x 55° CD horn 90° x 55° CD horn
Active x-over frequency 2.5 kHz FIR X-Over with
48 dB/oct.
2.5 kHz FIR X-Over with
48 dB/oct.
2.5 kHz FIR X-Over with
48 dB/oct.
2.5 kHz FIR X-Over with
48 dB/oct.
2.5 kHz FIR X-Over with
48 dB/oct.
75 Hz – 150 Hz, switchable 75 Hz – 150 Hz, switchable
Audio ports 1x XLR–1/4"-Combo In,
bal., 1x XLR-Through
1x XLR–1/4“-Combo In,
bal., 1x XLR-Through
1x XLR–1/4“-Combo In,
bal., 1x XLR-Through
1x XLR–1/4“-Combo In,
bal., 1x XLR-Through
1x XLR–1/4“-Combo In,
bal., 1x XLR-Through
2x XLR–1/4“-Combo In,
2x XLR L/R Out Mid/
High,2x XLR Through
balanced
2x XLR–1/4“-Combo In,
2x XLR L/R Out Mid/
High,2x XLR Through
balanced
Equalizer Tone knob (Music /
Speech) Bass Boost
Tone knob (Music /
Speech) Bass Boost
Tone knob (Music /
Speech) Bass Boost
Tone knob (Music /
Speech) Bass Boost
Tone knob (Music /
Speech) Bass Boost
Angles up 35°
33° 42°
Pole mount DuoTilt 3/7 DuoTilt 3/7
DuoTilt 3/7 DuoTilt 3/7 DuoTilt 3/7 1x M20 2x M20
Suspension points 3x M8 3x M8
3x M8 3x M8 3x M8
Grips 1, integrated 2, integrated
2, integrated 2, integrated 2, integrated 2, integrated 2, integrated
Casters
optional 100 mm
Housing MDF MDF
MDF MDF MDF MDF MDF
Front grille 2 mm metal grille backed
with black acoustic foam
2 mm metal grille backed
with black acoustic foam
2 mm metal grille backed
with black acoustic foam
2 mm metal grille backed
with black acoustic foam
2 mm metal grille backed
with black acoustic foam
2 mm metal grille backed
with black acoustic foam
2 mm metal grille backed
with black acoustic foam
Finish Acrylic enamel, black Acrylic enamel, black
Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black Acrylic enamel, black
Optional accessories Protective cover, Satellite
Add-on
Protective cover, Satellite
Add-on
Protective cover, Satellite
Add-on
Protective cover, Satellite
Add-on
Protective cover, Satellite
Add-on
Protective cover, Satellite
Add-on
Protective cover, Satellite
Add-on
Dimensions (WxHxD) 38 x 49 x 29 cm 39 x 57 x 36 cm
40 x 59 x 31 cm 47 x 62 x 42 cm 47 x 62 x 45 cm 53 x 61 x 64 cm 36 x 61 x 53 cm
Weight 13.2 kg / 29.1 lbs. 18.7 kg / 41.2 lbs.
16.3 kg / 35.9 lbs. 23.7 kg / 52.3 lbs. 22.6 kg / 49.8 lbs. 39.8 kg / 87.8 lbs. 27.2 kg / 60 lbs.
*@10% THD
