−12−
1.Operation Outline
OPERATION
GRAPH
・Time axis & Digital
meter indicator display．
・Data logging of 6 items
for up to 600 seconds.
GRAPH SELECT
・GRAPH1-6
・ENDLESS LOG
S
E
L
E
C
T
B
A
C
K
ANALOG
・3analog meters
Switch by the enter
button.
・1analog meter + 6 digital
meters
ANALOG SELECT
・ANALOG 1 - 6
・METER COLOR
・DIGITAL METER
S
E
L
E
C
T
B
A
C
K
Ｓ
Ｄ
Ｆ
PAST
・6 items can be shown.
TIME (Elapsed Time)
DISTANCE (Distance Driven)
SPEED (Average speed)
FUEL (Fuel consumption)
ECO (Average fuel efficiency)
COST (Fuel cost)
・Channel is selectable from
A to D.
・Under channel A, the automatic
measurement is available in
SET UP Mode.
[MENU]
