86212 x1
CNC Rear shock tower
4x13mm
3x15mm
3x12mm
86214 x1
Rear body post
88032 x2
Flange ball
88115 x4
Alum collar
31418 x2
4x18mm
F/H screws
32320 x4
3x20mm
Screws
31315 x2
3x15mm
screws
33312 x2
3x12mm
Tapping screw
87031 x2
Steel shock ball
3x20mm
3x20mm
4x18mm
23
24
25
T LT L
T
LT
L
33413T x2
4x13mm
TP screws
9
Assembly of Rear Shock Stay
Assembly of Rear Shock Stay
Assembly of Rear Gear Box onto Chassis
