59mm
31418 x2
4x18mm
F/H screws
4x18mm
87055 x4
Steering ball end
86015 x2
4x45mm
Turnbuckle
3x16mm
3mm
TL
TL
3x16mm
86017 x2
3mm
Nut
87055 x4
6.8mm
Ball
86003 x1
Front bumper
17
18
19
Assembly of Steering Rod
Assembly of Steering Rod
Assembly of Front Bumper
R
L
X2
T
L
T
L
31316 x4
3x16mm
screws
7
