HoBao Pro Hyper ST - 41 Assembly of Clutch-Step-1; 42 Assembly of Clutch-Step-2; 43 Assembly of Engine onto Chassis

Notice the clutch spring
1
2
*The fitting is in good position
if there is a clear gear-teething
mark on the paper after sliding out.
*The fitting is in good position
if there is a clear gear-teething
mark on the paper after sliding out.
86121
CNC New Clutch shoe
86122
Clutch spring
32308 x1
3x8mm
Cap screws
84187W x1
3.1x6mm
Washer
84187W x2
5x8mm
Washer
84077
5x10x4mm
Bearing
3.1x6mm
5x8mm
5x10x4mm
5x8mm
84077
5x10x4mm
88232
(14T) Lighten Clutch bell
3x8mm
33407 x4
4x7mm
Engine screw
4x7mm
41
42
43
Assembly of Engine onto Chassis
Assembly of Clutch-Step-2
Assembly of Clutch-Step-1
T
L
T
L
T
L
T
L
T
L
T
L
15
88226
88226
