33312T x2
3x12mm
Tapping screw
31312T x8
3x12mm
Tapping screw
3x12mm
3x12mm
3x12mm
52
Assembly of Radio Tray and Receiver box onto Chassis
53
2x8mm
ON / OFF
Switch
87084 x1
Receiver box
33208 x2
2x8mm
Tapping screw
84133 x1
Switch cap
19
Assembly of Switch into Receiver Box
