SECTION 9 − MIG WELDING (GMAW) GUIDELINES
9-1. Typical MIG Process Connections
Y Weld current can damage
electronic parts in vehicles.
Disconnect both battery
cables before welding on a
vehicle. Place work clamp as
close to the weld as possible.
Wire Feeder/
Power Source
Workpiece
Gun
Regulator/
Flowmeter
Gas Hose
Shielding Gas
Work Clamp
light mig 5/97 / Ref. 804 688-A
