Processes
OM-925 217 694B
August 2004
Handler 140 / 180
And H-10 Gun
Arc Welding Power Source And
Wire Feeder
Description
MIG (GMAW) Welding
Flux Cored (FCAW) Welding
Visit our website at
www.HobartWelders.com
R

Table of Contents

Questions and Answers

  • D
    Daniel DiazAug 7, 2025
    Why is there no weld output, wire doesn't feed, but the fan doesn't run on my Hobart Welding System?
    • E
      Erik TranAug 7, 2025
      Here are a few things to check: * Make sure the power cord is securely plugged into the receptacle. * Check and replace the building line fuse or reset the circuit breaker if it's open. * Ensure the power switch is in the On position. * Reset the welding power source circuit breaker if it's open.
  • J
    joshua03Aug 13, 2025
    Why is there no weld output, but the wire feeds on my Hobart Welding System?
    • P
      pramseyAug 13, 2025
      If you're getting wire feed but no weld output, try these solutions: * Ensure the work clamp has good metal-to-metal contact. * Replace the contact tip. * Verify proper polarity connections. * Tighten the thumbscrew securing the gun end to the feed head adapter.
  • B
    Bradley ParkAug 19, 2025
    What to do if electrode wire feeding stops during welding with my Hobart Welding System?
    • R
      rebekahsosaAug 19, 2025
      If the electrode wire stops feeding during welding, consider these steps: * Straighten the gun cable or replace any damaged parts. * Adjust the drive roll pressure. * Change to the correct drive roll groove. * Readjust the hub tension. * Replace the contact tip if it's blocked. * Clean or replace the wire inlet guide or liner if they're dirty or plugged. * Replace the drive roll or pressure bearing if they're worn or slipping. * Secure or repair the gun trigger leads. * Check and clear any restrictions at the drive assembly and liner. * Release the gun trigger and allow the gun and motor protection circuitry to reset. * Ensure the gun is secured to the feed head by tightening the thumbscrew. * Have a Factory Authorized Service Agent check the drive motor.
  • J
    Jeffrey SalinasAug 25, 2025
    Why is there no weld output, wire doesn't feed, but the fan motor continues to run on my Hobart Welding System?
    • R
      Ryan BanksAug 26, 2025
      If you have no weld output and the wire isn't feeding, but the fan motor is still running, here's what you can check: * If the thermostat TP1 is open due to overheating, let the fan run with the gun trigger switch off to cool the unit down until the thermostat closes. * Check the Voltage range switch position and ensure it 'clicks' into the desired range setting. * Ensure the Voltage range switch isn't set to the 'PURGE' position; set it to position 1, 2, 3, or 4. * Make sure the gun trigger leads are secure.
  • J
    justinsandersAug 31, 2025
    How to fix low weld output on my Hobart Welding System?
    • J
      jesse56Sep 1, 2025
      If you're experiencing low weld output, try the following: * Connect the unit to the correct input voltage or check for low line voltage. * Place the voltage switch in the appropriate position.

Summary

Safety Precautions

Symbol Usage

Explains symbols used for warnings and safety messages.

Arc Welding Hazards

Details dangers associated with arc welding processes.

Additional Symbols For Installation, Operation, And Maintenance

Covers symbols for installation, operation, and maintenance hazards.

California Proposition 65 Warnings

Provides specific state warnings regarding hazardous chemicals.

Principal Safety Standards

Lists key safety standards and codes applicable to welding.

EMF Information

Discusses electromagnetic fields and potential interference.

Definitions

Symbols And Definitions

Defines technical symbols used in the manual.

Specifications

Specifications

Provides technical specifications for the welding unit.

Duty Cycle And Overheating

Explains duty cycle limits and overheating prevention.

Volt-Ampere Curves

Shows voltage and amperage output capabilities.

Installation

Installing Welding Gun

Step-by-step guide for connecting the welding gun.

Installing Work Clamp

Instructions for attaching the work clamp.

Process;Polarity Table

Details polarity and cable connections for different processes.

Changing Polarity

Instructions on how to switch polarity.

Installing Gas Supply

Guide for connecting the shielding gas supply.

Electrical Service Guide For 230 VAC Model

Details electrical requirements for 230V operation.

Installing Wire Spool And Adjusting Hub Tension

Guide for loading wire and setting spool tension.

Threading Welding Wire

Step-by-step process for feeding welding wire.

Operation

Controls

Description of the unit's control panel features.

Weld Parameter Chart For 115 VAC Model

Recommended settings for 115V welding.

Weld Parameter Chart For 230 VAC Model

Recommended settings for 230V welding.

Maintenance & Troubleshooting

Routine Maintenance

Schedule and procedures for regular upkeep.

Overload Protection

Explanation of the overload protection system.

Drive Motor Protection

Details on the drive motor protection circuit.

Changing Drive Roll Or Wire Inlet Guide

Instructions for replacing wire feed components.

Replacing Gun Contact Tip

Guide for replacing the contact tip.

Cleaning Or Replacing Gun Liner

Procedure for cleaning or replacing the gun liner.

Replacing Switch And;Or Head Tube

Steps for replacing gun switches or head tubes.

Troubleshooting Table

Guide to diagnose and fix common operational issues.

Electrical Diagram

MIG Welding (GMAW) Guidelines

Typical MIG Process Connections

Diagram showing typical setup for MIG welding.

Typical MIG Process Control Settings

Guidelines for setting up MIG welding parameters.

Holding And Positioning Welding Gun

Techniques for proper gun handling and positioning.

Conditions That Affect Weld Bead Shape

Factors influencing the quality of the weld bead.

Gun Movement During Welding

Recommended gun movements for different weld types.

Poor Weld Bead Characteristics

Examples and identification of common weld defects.

Good Weld Bead Characteristics

Examples and identification of desirable weld characteristics.

Troubleshooting - Excessive Spatter

Solutions for excessive spatter during welding.

Troubleshooting - Porosity

Solutions for porosity defects in welds.

Troubleshooting - Excessive Penetration

Solutions for welds with excessive penetration.

Troubleshooting - Lack Of Penetration

Solutions for welds with insufficient penetration.

Troubleshooting - Incomplete Fusion

Solutions for incomplete fusion in welds.

Troubleshooting - Burn-Through

Solutions for burn-through defects.

Troubleshooting - Waviness Of Bead

Solutions for wavy weld beads.

Troubleshooting - Distortion

Solutions for weld distortion issues.

Common MIG Shielding Gases

Chart of common shielding gases and their applications.

Troubleshooting Guide For Semiautomatic Welding Equipment

General troubleshooting for wire feeding and gas flow.

Parts List

Optional Drive Rolls

Lists part numbers for different wire diameter drive rolls.

Options

Lists optional accessories and their part numbers.

Hobart Welding Products Handler 180 Specifications

General IconGeneral
Input Voltage230 V
Input Hz60 Hz
Amperage Range25 - 180 A
Input PhaseSingle Phase
Spool Size Capacity4 or 8 in
Wire Size Range.023 - .035 in
ProcessMIG
Wire Feed Speed Range50-700 IPM
