701 S Ridge Avenue, Troy, OH 45374
1-888-4HOBART • www.hobartcorp.com
F-40089 – Legacy
®
HL200 Mixer Page 3 of 4
LEGACY
®
HL200 MIXER
SPECIFICATIONS
MOTOR:
1
2 H.P. high torque motor.
100-120/50/60/1 8.0 Amps
200-240/50/60/1 5.0 Amps
ELECTRICAL:
100-120/50/60/1, 200-240/50/60/1UL Listed.
CONTROLS:
Magnetic contactor with thermal overload protec-
tion. Internally sealed “Start-Stop” push buttons.
A 15-minute SmartTimer™ is standard.
SmartTimer™ includes Automatic Time Recall,
which remembers the last time set for each speed.
Optional SmartPlus2™ Programmable Recipe
Timer allows operators the ability to program up
to 4 recipes with 5 steps per recipe. SmartPlus2™
automatically changes speeds and starts timer
count-down without operator intervention.
TRANSMISSION:
Gear-driven. Gears are constant mesh heat-treated
hardened alloy steel along with anti-friction ball
bearings. Grease lubricants furnished to all gears
and shafts.
SPEEDS:
Agitator
(RPM)
Attachment
(RPM)
Stir 59 33
First (Low) 107 61
Second (Intermediate) 198 113
Third (High) 365 207
BOWL GUARD:
Heavy-duty stainless steel wire front and solid rear
portion. Front portion of guard rotates easily to
add ingredients and install or remove agitator.
It detaches in seconds for cleaning in dishwasher or
sink. Rear portion of guard can be quickly cleaned
in position. Guard must be in closed position before
mixer will operate. Bowl support interlock provides
further protection.
BOWL LIFT:
Ergonomic style, hand crank operated, self-locking in
top and bottom position.
FINISH:
Metallic Gray Hybrid Powder Coat nish.
ATTACHMENT HUB:
Comes with front-mounted Hobart standard #12
taper attachment hub for use with Hobart #12 size
attachments.
ATTACHMENTS AND ACCESSORIES:
The following are available at extra cost:
Stainless Steel Bowl
“B” Flat Beater
“C” Wing Whip
“D” Wire Whip
“E” Dough Hook
“ED” Dough Hook
“P” Pastry Knife
Bowl Splash Cover
Bowl Scraper
Ingredient Chute
12 Quart Accessories
9" Vegetable Slicer
Meat Chopper Attachment
Rubber Foot Pads
Attachment Tray Support
Listed by Underwriters Laboratories Inc. and certied by NSF
International.
Hobart Bowl Scraper
Hobart Ingredient Chute
HL200 Mixer Technical Manual Page 5 of 111
