– 8 –
OPERATION
INITIAL CHECKS
To avoid risk of serious injury, keep hands, feet, clothing, and utensils away from
the bowl, bowl support, slideways, and agitator when the mixer is in operation or when any of
the components are moving.
This food mixer is only for professional use by properly trained persons.
Ensure operators have read and understood this manual and have received
proper training.
Do not use the mixer without the interlocked wire cage in place.
The Legacy+
®
mixer is equipped with SmartTimer™ controls and a power bowl lift. Other operating parts
(Fig. 3, Fig. 4, and Fig. 5) and their functions are described throughout the Operation section.
The wire cage must be in position or the mixer will not operate.
The bowl must stay in the locked position on the bowl support or the mixer will not operate.
If the bowl support is not all the way up (mix position), the mixer will not operate unless the START button
is pressed and held.
If the bowl support is not in the mix position and the START button is pressed and held, the mixer will
operate only in STIR speed.
Check Lubrication Before Use
This mixer is shipped with oil in the transmission.
Check oil level before starting mixer (Fig. 2). Refer
to the Lubrication section for applicable lubrication
procedures.
Wiring Check
1. Turn the SPEED dial pointer to STIR.
2. Apply power to the mixer. With the bowl
locked into place, the bowl support all the
way up and wire cage closed, momentarily
run the machine by pushing the START and
then STOP buttons.
3. Verify that the bowl lift raises and lowers per the switch direction arrows. If not, proceed to step
3a below.
a. Refer to the Electrical Connections section and follow all warnings and instructions to correct
the lead wires.
Fig. 2
Transmission Fill Plug / Oil Dipstick
