HOBBYEAGLE A3 Mini User Manual

WWW.HOBBYEAGLE.COM 12 / 12
PROGRAMMING
To setup the gyro, download and install the latest HobbyEagle A3 Configurator and the USB driver from
our website at https://www.hobbyeagle.com/a3-configurator/
 The software supports Windows XP, Windows 7, Windows 8 and Windows 10 (32 or 64 bit).
 If the installation fails, please download and install Microsoft .NET Framework 4 first.
 Install the USB driver (CP210X_VCP) before connecting the gyro to the PC.
Related Documents
Installation Guide https://www.hobbyeagle.com/a3-configurator/docs/installation_guide_en.pdf
USB Driver Installation Guide https://www.hobbyeagle.com/a3-configurator/docs/usb_installation_guide_en.pdf
Quick Start Guide https://www.hobbyeagle.com/a3-configurator/docs/quick_start_guide_en.pdf
Firmware Update Guide https://www.hobbyeagle.com/a3-configurator/docs/firmware_update_guide_en.pdf
VERY IMPORTANT!
 ALWAYS use the special USB adapter and data cable included in the package while
connecting the gyro to a PC or the programming card. The common USB cables for
mobile phones or other products will not work with our gyros!
 It is recommended to use the new Program Card X for A3 Mini and keep the firmware update
to the latest version.
SPECIFICATIONS
Main Controller:
32-bit MCU
Sensors:
High-precision 3-axis gyroscope and 3-axis accelerometer
Gyroscope Scale Range:
±2000dps
Accelerometer Scale Range:
±4g
PWM:
800 ~ 2220uS, Neutral 1500/1520uS, 50Hz ~ 333Hz
Input Voltage:
DC 3.6V ~ 8.4V
Operating Temperature:
-10℃ ~ 50℃
Size:
30×19.5×7.5mm
Weight:
4.8g (excluding wires)
