WWW.HOBBYEAGLE.COM 3 / 12
INSTALLATION
NOTES
Never use the hot-melt glue or nylon ties to fix the gyro onto the airplane!
You need only one piece of the double-sided tapes each time, a mounting type that is too soft
or too thick can affect performance of the gyro.
The gyro is a sensing device, please make enough space around it and keep as far away from
other electronic devices or wires as possible.
Mounting Orientation
Use one of the supplied double-sided tapes to attach the gyro to the airplane firmly. For best performance,
the gyro should be mounted as close to the C.G. as possible, and the housing edges must be aligned
exactly parallel to all three rotation axes of the airplane. The gyro can be attached flat or upright, and
even upside down, however, you must ensure the arrow on the sticker always point to the heading
direction, otherwise the gyro will not work normally in ANGLE, LEVEL and HOVER modes.
① Flat, face up ② Flat, face down
③ Upright, button down ④ Upright Inverted, button up
To Next Page
