List of Parts
Tools necessary/outils nécessaires/ :
⇒ 2 wrenches - No. 17
⇒ 1 pair of universal pliers
It is advisable to have 2 people to assemble the
Hobie FX-One .
LIST OF PARTS
1 Hulls (2)
2 Front crossbar
3 Rear crossbar
4 Mast
5 Boom
6 Trampoline & rod
7 Rigging bag
8 Wire bag
9 Ropes bag
10 Daggerboards (2)
11 Rudder assemblies (2)
12 Tiller crossbar
13 Tiller extension
14 Mainsail
15 Batten set
