Configuration 29
HIT-4U HP-327
OUTPUT MENU
Menu Item Description Options Min
Max
Value
Default
ANALOG
Analog Out
Function.
OFF
RATE
4mA
12mA
20mA
N/A OFF
OUT LO
4 mA setting in
units selected
for Total .
OUT LO must
be < OUT HI.
Numeric
Entry
0.000
999998
0.000
OUT HI
20 mA setting in
units selected
for Total. OUT
HI must be >
OUT LO.
Numeric
Entry
0.001
999999
100.000
PULSE
Pulse Function OFF
ON
TEST
N/A OFF
WIDTH Pulse width in
mS
Numeric
Entry
4 ms
300 ms
4 ms
SCALE
Pulse Scale.
This factor
represents the
number of
output pulses
per least
significant digit
of displayed
total determined
by the total
decimal
selection.
0.01
0.1
1
10
100
N/A 1
