Hofmann Megaplan MS400-2 - Gauge and Cylinder Unit Replacement

GAUGE UNIT AND CYLINDER UNIT REPLACEMENT
Models:
M400-2(C) - M400P-2(C) - M400P-2(D)
Nr.
Description
1
Remove the weight tray
(see the relative instructions)
Remove the encoder
(see the relative instructions)
2
Mark (with a felt-tip pin) the position of the plate on
the base
(this will allow correctly aligning the plate when
refitting it)
SHEET 012
