Hofmann Megaplan MS400-2 - Mechanical Brake Removal Steps

MECHANICAL BRAKE REMOVAL
Model:
M400-2(C) - M400P-2(C) - M400P-2(D)
No.
Description
1
Remove the weight shelf
(see relative instructions)
Remove the gauge unit
(see relative instructions)
Remove the encoder
(see relative instructions)
2
Detach the spring
3
Detach the pedal rod
SHEET 022
