Hofmann Megaplan MS400-2 - Piezo Sensor Replacement Guide

PIEZO SENSOR REPLACEMENT
Models:
M400-2(C) - M400P-2(C) - M400P-2(D)
No.
Description
1
Remove the weight tray
(see the relative instructions)
Remove the gauge unit and the cylinder unit
(see the relative instructions)
Remove the encoder
(see the relative instructions)
2
Disconnect the motor, capacitor and power supply
cables, and the flat cable
Disconnect the piezo extension cable
SHEET 013
