PIEZO INSULATION TEST
Model:
M400-2(C) - M400P-2(C) - M400P-2(D)
No.
Description
1
Use a megohmmeter with a full scale of min.
3000 MΩ
2
Test the insulation between the dynamic sensor
poles between the blue and the yellow wires
MIN 2000 MÙ
3
Test the insulation between the yellow wire and the
machine body
MIN 2000 MÙ
SHEET 026
