BA / ETL duolift MTE 3000 – 94 12 554
21
1 1953000 Door stop
2 1953002 Raised countersunk head screw (swing arm)
3 6490797 Vertically adjustable pick-up pad assy
4 1953012 Small V-belt pulley (motor)
5 1953013 V-belt
6 1953015 Ball bearing (spindle, bottom)
7 1953017 Contact washer (spindle, top)
8 1953019 Cover plate (plastic)
9 1701491 Cover (1 off)
10 1953022 Rollers (1 set = 4 off), lifting carriage
11 1953027 Short telescopic swing arm, left (asymmetrical)
12 1953028 Short telescopic swing arm, right (asymmetrical)
13 1953029 Long telescopic swing arm, right (asymmetrical)
14 1953013 Long telescopic switch arm, left (asymmetrical)
15 1953031 Lifting nut assy
16 1953032 Safety nut assy
17 1953033 Guide rollers (2 off) lifting carriage
18 1953034 Fitted bolt assy
20 1953043 Arm lock assy
23 1953046 Base plate
24 1953055 Cover band (spindle cover)
25 1953051 Lifting spindle
26 1953059 Lifting carriage
27 1953062 Fastening means, base plate (8 x M 16 x 40)
28 1953066 Bearing bush with fastening means (secondary column)
29 1953039
1953101
Motor mounting plate, secondary column
Motor mounting plate, primary column
31 1953088 Control box assy
32 1953080 Operating switch
34 1953069 Cable control with tension spring
35 1953064 Limit switch operating plate
with setscrew
36 1953021 Cap (lifting nut, plastic)
37 1953093 Distance bush assy, spindle top
38 1953036 Angular ball bearing, spindle top
39 1953086 Potentiometer
40 1953087 Holder for potentiometer
41 1953090
Pinion for potentiometer
setscrew, 1 off
42 1701261 Rubber pad for pick-up pad (1 off)
43 1953035 Motor assy
44 1953092 Controller board
46 1953094 Bearing flange assy
47 1953102 Contactor
1953045 Shim 0.5 mm
1953076 Fine-wire fuse 1 A
1953077 Fine-wire fuse 6.3 A
1953096 Auto-lubrication system (1 set for 1 column)
1953114 Oil for auto-lubrication system (1l)
1953097 Motor lead, primary side
1953098 Motor lead, secondary side
1953099 Potentiometer lead, primary side
1953100 Potentiometer lead, secondary side
Accessory 1953037 Tool trays (1 set = 2 off)
Accessory 1953089 Overhead cable duct (height approx. 4.4 m)
Accessory 1953091 Manual override kit for arm lock
Accessory 1953095 Base frame for MTE 3000
Accessory 4235957 Heavy-duty anchor bolt HSL-G-TZ M 16 / 100 (Hilti), 1 off
13. Spare parts list
Item HWT no. Description
1 1953000 Door stop
2 1953002 Raised countersunk head screw (swing arm)
3 6490797 Vertically adjustable pick-up pad assy
4 1953012 Small V-belt pulley (motor)
5 1953013 V-belt
6 1953015 Ball bearing (spindle, bottom)
7 1953017 Contact washer (spindle, top)
8 1953019 Cover plate (plastic)
9 1701491 Cover (1 off)
10 1953022 Rollers (1 set = 4 off), lifting carriage
11 1953027 Short telescopic swing arm, left (asymmetrical)
12 1953028 Short telescopic swing arm, right (asymmetrical)
13 1953029 Long telescopic swing arm, right (asymmetrical)
14 1953013 Long telescopic switch arm, left (asymmetrical)
15 1953031 Lifting nut assy
16 1953032 Safety nut assy
17 1953033 Guide rollers (2 off) lifting carriage
18 1953034 Fitted bolt assy
20 1953043 Arm lock assy
23 1953046 Base plate
24 1953055 Cover band (spindle cover)
25 1953051 Lifting spindle
26 1953059 Lifting carriage
27 1953062 Fastening means, base plate (8 x M 16 x 40)
28 1953066 Bearing bush with fastening means (secondary column)
29 1953039
1953101
Motor mounting plate, secondary column Motor mounting plate, primary column
31 1953088 Control box assy
32 1953080 Operating switch
34 1953069 Cable control with tension spring
35 1953064 Limit switch operating plate with setscrew
36 1953021 Cap (lifting nut, plastic)
37 1953093 Distance bush assy, spindle top
38 1953036 Angular ball bearing, spindle top
39 1953086 Potentiometer
40 1953087 Holder for potentiometer
41 1953090 Pinion for potentiometer setscrew, 1 off
42 1701261 Rubber pad for pick-up pad (1 off)
43 1953035 Motor assy
44 1953092 Controller board
46 1953094 Bearing flange assy
47 1953102 Contactor
1953045 Shim 0.5 mm
1953076 Fine-wire fuse 1 A
1953077 Fine-wire fuse 6.3 A
1953096 Auto-lubrication system (1 set for 1 column)
1953114 Oil for auto-lubrication system (1l)
1953097 Motor lead, primary side
1953098 Motor lead, secondary side
1953099 Potentiometer lead, primary side
1953100 Potentiometer lead, secondary side
6467811 Brake segment 467811/4
1611178 Compression spring, 180 dia., 1.1 x 9.3 x 26
Accessory 1953037 Tool trays (1 set = 2 off)
Accessory 1953089 Overhead cable duct (height approx. 4.4 m)
Accessory 1953091 Manual override kit for arm lock
Accessory 1953095 Base frame for MTE 3000
Accessory 4235957 Heavy-duty anchor bolt HSL-G-TZ M 16 / 100 (Hilti), 1 off
