Holder C250 - Operating Elements from Drivers Seat, Foot

To Next Page

To Previous Page

Description C250 ... C370

56 Translation of Original Operating Manual 156319-04

Operating elements from driver's seat, foot

pedals

C370_001

C350, C370

1 Inch pedal

2 Brake pedal

3 Accelerator pedal (throttle pedal in SDS

mode)

4 Engine speed fine adjustment control
