Holman WS5056C - Installation

INSTALLATION
All in one outdoor data collector , solar powered
• Frequency:917MHz
• Transmissionrange:100metersinopenarea.
 **Actualdistancemaybevarieddependingupontheenvironment,andcanbe
shortened by interference such as concrete walls.
• Solarpowered+built-inRechargeablebattery:3.7V,1800maH
Installation
• Already tted with Lithium Poly (LIPO) rechargeable battery.
• OpenthebatterycoverlocatedatthebackofthemainunitandremoveLIPObattery
and charge it with the charger supplied. This should not take longer than one hour.
• Beforeclosingthebatterycover,pushtheinsideblackswitchfromOFFtoON(very
 important),andcheckiftheredLEDlightisashingwhentheswitchisturnedtoON,
this means the transmission is working. Then close the battery cover properly.
• TheredLEDlightwillashapproximatelyevery1minutewhentransmittingthesignal
to the inside main unit.
The Indoor Receiver
• TheIndoorReceivercanbeplacedontoanyatsurfaceorwallmountedatthedesired
 locationbythehanginghole,Itisimportanttocheckthattheradiosignalcanbe
received before mounting.
SWITCH
