Product data
All weights and dimensions are for standard model without attachment. For extra equipment, please contact
Holms for further information.
2.5 3.0 3.5
Working width (m) 2.5 3.0 3.5
Max. width (m) 2.7 3.2 3.7
Max. height (m) 1.52 1.52 1.52
Working width, fully turned 30° (m) 2.2 2.6 3.0
Weight with std. plastic brush (kg) 470 500 530
Weight with sprinkler system, empty tank (kg) 200 200 200
Centre of gravity, dimension A standard equipment (mm) 1110 1120 1130
Centre of gravity, dimension B standard equipment (mm) 300 300 300
Centre of gravity, dimension A with sprinkler system, empty tank (mm) 1100 1110 1120
Centre of gravity, dimension B with sprinkler system, empty tank (mm) 220 220 220
Centre of gravity, dimension A with sprinkler system, full tank (mm) 760 770 780
Centre of gravity, dimension B with sprinkler system, full tank (mm) 220 220 220
Max. oil flow (litres/min) 210 210 210
