Home Styles Monarch - Monarch Buffet Parts and Hardware; Part List; Hardware List

Part List
Hardware List
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Cam Lock Screw
18 pcs.(+1 extra)
88 5020 612
Monarch Buffet
Also need Part in carton 88 5020 611
Head Cap Bolt
(long)
18 pcs. (+1 extra)
Hex Wrench
1 pc.
Wood Screw (short)
for Drawer Base Part
8 pcs. (+1 extra)
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver Tools recommended for assembly : Level
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
(Knock-Down Construction, please refer
to the last page of these instructions
for steps to assemble drawers)
S.
Drawer
2 pcs.
L.
Front Rail
1 pc.
B.
Front Post
1 pc.
C.
Front Post
1 pc.
D.
Side Panel
1 pc.
E.
Side Panel
1 pc.
F.
Middle Panel
1 pc.
G.
Support
Runner
1 pc.
H.
Support
Runner
1 pc.
M.
Back Rail
2 pcs.
K.
Front Rail
1 pc.
J.
Front Rail
1 pc.
Q.
Back Post
2 pcs.
R.
Back Panel
3 pcs.
O.
Door
1 pc.
P.
Door
1 pc.
N.
Bottom
1 pc.
I.
Shelf
4 pcs.
Knob
4 pcs.
Head Cap Bolt
(short)
8 pcs. (+1 extra)
Machine Screw
4 pcs.
Wood Screw (long)
for Drawer Side Part
16 pcs. (+1 extra)
Wood Screw
4 pcs. (+1 extra)
Flat Washer
4 pcs. (+1 extra)
Adjustable Pin
16 pcs. (+1 extra)
Wood Screw (short)
for Back Panel
12 pcs. (+1 extra)
Cam Lock
18 pcs.(+1 extra)
Steel Connector
4 pcs.
