SPECIFICATIONS
Engine displacement 45 cm
3
Maximum engine performance
(in accordance with ISO 8893) 1.4 kW / 1.9 HP
Maximum rotational frequency
of the the spindle 7000 min-
1
Engine speed (rotational frequency)
at recommended max. spindle
rotational frequency 9000 min-
1
Engine speed (rotational frequency)
at idle 2250-2750 min-
1
Fuel consumption (in accordance
with ISO 8893) at max.
engine performance 0.85 kg/h
Specific fuel consumption
(in accordance with ISO 8893)
at max. engine performance 0.45 kg/h
Vibration level idling
- Left handle 7.3 m/s
2
- Right handle 7.5 m/s
2
Vibration level racing
- Left handle 7.2 m/s
2
- Right handle 7.5 m/s
2
Sound pressure level
(in accordance with EN ISO 11806:
1997, ISO 7917:1987) 102 LpA (dBA)
Sound power level
(in accordance with ISO 10884) 115 LwA (dBpA)
DESCRIPTION
1. M6 wrench
2. Hole of the gear case
3. Hole in the upper flange washer
4. Upper flange washer
5. Blade cover
6. Blade
7. Cupped washer
8. Washer
9. Blade nut
10. Gear case
11. Spark plug wrench
12. String head
13. Connector
14. Grass deflector
15. Screw for grass deflector
16. Locking tab
17. Notch
18. Handle bar
19. Bottom clamp
20. Shaft
21. Throttle trigger
22. Top clamp
23. Latch
24. Strap hanger
25. Quick release tap
26. Mounting bracket
27. Best cutting area
28. Dangerous cutting area
29. Ignition switch
30. Primer bulb
31. Lever
32. Blade protector
33. Filter
34. Spool retainer
35. Spool
36. Spring
37. Slots for spool
38. Eyelets
39. First string
40. Anchor hole
41. Arrows on spool
42. Second string
ASSEMBLY
HANDLE (Fig. 2)
■ Place the handle bar (18) in the bottom clamp (19)
located on the shaft (20) housing.
Note: The throttle trigger (21) must be mounted to the
operator's right side.
■ Place the top clamp (22) on top and tighten the four
M5 x 25 screws.
■ Adjust the handle bar for best operator control in a
comfortable upright position.
ATTACHING THE SHOULDER STRAP (Fig. 3)
■ Connect the latch (23) on the shoulder strap to the
strap hanger (24).
■ Adjust the shoulder strap hanger to a balanced
position where the blade or cutter attachment will
suspend between 100 mm to 300 mm above the
ground surface.
■ Adjust the strap hanger to a comfortable position.
Note: To quickly release the product from the
shoulder strap, sharply pull the quick release tab (25).
GRASS DEFLECTOR AND BLADE GUARD USE
(Fig. 4)
Note: When converting from brushcutter to string trimmer
or string trimmer to brushcutter, make sure the correct
guard/deflector is being used.
