Honda 08E91-E22-100A - Page 4

4 of 23 AII 38576-38846 (0802) © 2008 American Honda Motor Co., Inc. – All Rights Reserved.
6. Remove the cover from the trunk lid/fuel fill door
opener (six retaining tabs), and remove one
self-tapping screw. Make sure the trunk lid/fuel fill
door opener is unlocked.
711104BY
SELF-TAPPING
SCREW
Unlock.
KEY
TRUNK LID/FUEL
FILL DOOR OPENER
6 RETAINING
TABS
COVER
FRONT
7. Raise the front portion of the left front door sill trim
(six clips, one retaining tab, and one hook).
8. Pull away the weatherstrip, and remove the left kick
panel (two clips).
711106BY
LEFT FRONT
DOOR SILL TRIM
HOOK
6 CLIPS
FRONT
RETAINING
TAB
7111080Y
2 CLIPS
WEATHERSTRIP
LEFT KICK
PANEL
