Honda 08E91-E22-100A - Page 5

© 2008 American Honda Motor Co., Inc. – All Rights Reserved. AII 38576-38846 (0802) 5 of 23
9. Pull away the weatherstrip and remove the left
dashboard side cover (seven retaining tabs and
three hooks).
10. Lower the tilt lever and pull the steering wheel out.
11. Remove the upper steering column cover:
• Insert a flat-tip screwdriver along the column
guide inside the lower cover, and gently pry out
on the retaining tab of the upper column cover.
• Push the lower cover in at the areas shown to
release the two retaining tabs, and pull up on the
upper cover to release the two hooks.
6D1805BY
LEFT DASHBOARD
SIDE COVER
7 RETAINING
TABS
3 HOOKS
WEATHERSTRIP
12. Remove the lower steering column cover (three
screws). The upper screws are self-tapping screws.
7215010K
LOWER
STEERING
COLUMN
COVER
UPPER
STEERING
COLUMN
COVER
RETAINING
TAB
TILT LEVER
COLUMN
GUIDE
FLAT-TIP
SCREWDRIVER
2 HOOKS
2 RETAINING TABS
Push.
7111090Y
LOWER
STEERING
COLUMN
COVER
SELF-TAPPING
SCREWS
SCREW
