Honda 2006 CRF50F User Manual

＊
＊
$38.00
$48.00
$16.00
61GEL52
61CM002
31GEL660
2006 CRF50F Service Manual
Common Service Manual
2006 CRF50F Owner’s Manual
Price EachDescriptionPublication Item No.
Prices are subject to change without notice and without incurring obligation.
146
Authorized Manuals
Consumer Information
The Service Manual used by your authorized Honda dealer is available from Helm, Inc. (USA only,
Canada: See your Honda dealer to order authorized manuals.)
Also available but not necessary to service your model is the Honda Common Service Manual
which explains theory of operation and basic service information for various systems common to all
Honda motorcycles, motor scooters and ATVs.
These Honda manuals are written for the professional technician, but most mechanically-capable
owners should find them easy to use if they have the proper tools and observe proper safety
standards. Special Honda tools are necessary for some procedures.
05/03/15 18:01:31 31GEL660_155

Honda 2006 CRF50F Specifications

General

Engine Type	49cc air-cooled single-cylinder four-stroke
Bore x Stroke	39.0mm x 41.4mm
Compression Ratio	10.0:1
Induction	13mm piston-valve carburetor
Ignition	CDI
Transmission	Three-speed with automatic clutch
Front Suspension	Inverted telescopic fork; 3.5 inches travel
Front Brake	Drum
Rear Brake	Drum
Front Tire	2.50-10
Rear Tire	2.50-10
Wheelbase	36.0 inches
Seat Height	21.6 inches
Curb Weight	110 pounds
Fuel Capacity	0.7 gallons
Final Drive	420 chain; 14T/37T
Rear Suspension	Single shock; 2.8 inches travel
Rake	25.0°
