Honda Africa Twin CRF1100D 2022 User Manual

Removing & Installing Body Components u Front Seat
270
Maintenance
Front Seat
#
Removal
1. Remove the rear seat. 2 P. 273
2. Remove the front seat while pulling it
backward and upward.
#
Installation
1.
Insert the front lower prong and center
lower prongs into the front stay and center
stays on the fuel tank, and insert the rear
hooks into the upper slots.
Insert the front upper prong and center
upper prongs into the front stay and center
stays on the fuel tank, and insert the rear
hooks into the lower slots.
Front seat
When setting the high seat position:
When setting the low seat position:

Honda Africa Twin CRF1100D 2022 Specifications

General

Engine Type	Liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam
Displacement	1, 084 cc
Bore x Stroke	92 mm x 81.5 mm
Compression Ratio	10.1:1
Front Tire	90/90-21
Wheelbase	1, 575 mm
Lighting	Full LED Lighting
Transmission	6-speed manual
Fuel System	Electronic fuel injection
Fuel Tank Capacity	24.8 liters
Front Suspension	Showa 45mm inverted telescopic fork with adjustable preload, compression and rebound damping
Rear Suspension	Pro-Link with Showa gas-charged damper, adjustable preload and rebound damping
Front Brakes	Twin 310 mm discs, 4-piston calipers
Rear Brakes	Single 256 mm disc, 1-piston caliper
Rear Tire	150/70R18
Seat Height	850 mm
Instruments	6.5-inch TFT
Max Power Output	75 kW (101 hp) @ 7, 600 rpm
Torque	105 Nm (77 lb-ft) @ 6, 400 rpm
Curb Weight	236 kg (520 lbs)
