Honda Africa Twin CRF1100D 2022 User Manual

Storing Your Vehicle
349
Information
Storing Your Vehicle
If you store your vehicle outdoors, you should
consider using a full-body cover.
If you won't be riding for an extended period,
follow these guidelines:
● Wash your vehicle and wax all painted
surfaces (except matte painted surfaces). Coat
chrome pieces with rust-inhibiting oil.
● Lubricate the drive chain. 2 P. 259
● Place your vehicle on a maintenance stand
and position a block so that both tires are off
the ground.
● After rain, remove the body cover and allow
the vehicle to dry.
● Remove the battery (2 P. 267) to prevent
discharge. Fully charge the battery and then
place it in a shaded, well-ventilated area.
u If you leave the battery in place, disconnect
the negative
- terminal to prevent
discharge.
After removing your vehicle from storage,
inspect all maintenance items required by the
Maintenance Schedule.
For more information about storage, refer
to the Honda Winter Storage Guide, available
from your dealer.
For more information about storage,
visit our website at www.honda.ca and look up
“Storage Tips” under the “Honda Warranty” in
the Warranty tab for your Model.
USA
Canada

Honda Africa Twin CRF1100D 2022 Specifications

General

Engine Type	Liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam
Displacement	1, 084 cc
Bore x Stroke	92 mm x 81.5 mm
Compression Ratio	10.1:1
Front Tire	90/90-21
Wheelbase	1, 575 mm
Lighting	Full LED Lighting
Transmission	6-speed manual
Fuel System	Electronic fuel injection
Fuel Tank Capacity	24.8 liters
Front Suspension	Showa 45mm inverted telescopic fork with adjustable preload, compression and rebound damping
Rear Suspension	Pro-Link with Showa gas-charged damper, adjustable preload and rebound damping
Front Brakes	Twin 310 mm discs, 4-piston calipers
Rear Brakes	Single 256 mm disc, 1-piston caliper
Rear Tire	150/70R18
Seat Height	850 mm
Instruments	6.5-inch TFT
Max Power Output	75 kW (101 hp) @ 7, 600 rpm
Torque	105 Nm (77 lb-ft) @ 6, 400 rpm
Curb Weight	236 kg (520 lbs)
