Honda Africa Twin CRF1100D 2022 User Manual

318
Troubleshooting
Audio System Trouble
Symptom Cause/remedy
Unable to pair Bluetooth
®
device
Some Bluetooth
®
devices and application software you use may
be incompatible with the audio system and/or the operable
functions may be limited.
Check that the audio system and Bluetooth
®
device are both in
pairing mode.
2 P. 157 2 P. 162
The audio system may not be properly connected when another
Bluetooth
®
device is being paired at the same time. Check your
surroundings to make sure no other device being paired is
present before re-pairing. Presence of a Bluetooth
®
device in the
vicinity sometimes affects the pairing due to radio wave
interference, etc.
When connecting a Bluetooth
®
device, make sure no other
Bluetooth
®
device readied for pairing is present. Presence of a
Bluetooth
®
device in the vicinity sometimes affects the pairing
due to radio wave interference, etc.
When you repeatedly fail in pairing, delete the paired device once,
then try pairing again.
2 P. 157 2 P. 162

Honda Africa Twin CRF1100D 2022 Specifications

General

Engine Type	Liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam
Displacement	1, 084 cc
Bore x Stroke	92 mm x 81.5 mm
Compression Ratio	10.1:1
Front Tire	90/90-21
Wheelbase	1, 575 mm
Lighting	Full LED Lighting
Transmission	6-speed manual
Fuel System	Electronic fuel injection
Fuel Tank Capacity	24.8 liters
Front Suspension	Showa 45mm inverted telescopic fork with adjustable preload, compression and rebound damping
Rear Suspension	Pro-Link with Showa gas-charged damper, adjustable preload and rebound damping
Front Brakes	Twin 310 mm discs, 4-piston calipers
Rear Brakes	Single 256 mm disc, 1-piston caliper
Rear Tire	150/70R18
Seat Height	850 mm
Instruments	6.5-inch TFT
Max Power Output	75 kW (101 hp) @ 7, 600 rpm
Torque	105 Nm (77 lb-ft) @ 6, 400 rpm
Curb Weight	236 kg (520 lbs)
