Honda Africa Twin CRF1100D 2022 User Manual

Other Adjustments u Adjusting the Windscreen Height
305
Continued
Maintenance
Adjusting the Windscreen
Height
You can adjust the windscreen height 1 of 5
positions.
Windscreen height indicator shows the
windscreen height.
The standard position is 1.
u Do not adjust the windscreen while riding.
1. Push the right and left lock levers to unlock
the screen.
2. Continue to push the right and left lock
levers, move the right and left lock levers
upward or downward to raise or lower the
windscreen.
3. Release the right and left lock levers at the
desired position while checking height the
indicator.
u Make sure that the windscreen is locked
securely by slightly moving the right and
left lock levers up or down.
CRF1100A4/D4
Windscreen
Left lock
lever
Right lock
lever
Slider
123
4
5
Windscreen
height
indicator

Honda Africa Twin CRF1100D 2022 Specifications

General

Engine Type	Liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam
Displacement	1, 084 cc
Bore x Stroke	92 mm x 81.5 mm
Compression Ratio	10.1:1
Front Tire	90/90-21
Wheelbase	1, 575 mm
Lighting	Full LED Lighting
Transmission	6-speed manual
Fuel System	Electronic fuel injection
Fuel Tank Capacity	24.8 liters
Front Suspension	Showa 45mm inverted telescopic fork with adjustable preload, compression and rebound damping
Rear Suspension	Pro-Link with Showa gas-charged damper, adjustable preload and rebound damping
Front Brakes	Twin 310 mm discs, 4-piston calipers
Rear Brakes	Single 256 mm disc, 1-piston caliper
Rear Tire	150/70R18
Seat Height	850 mm
Instruments	6.5-inch TFT
Max Power Output	75 kW (101 hp) @ 7, 600 rpm
Torque	105 Nm (77 lb-ft) @ 6, 400 rpm
Curb Weight	236 kg (520 lbs)
