Honda Africa Twin CRF1100D 2022 User Manual

308
Troubleshooting
Engine Will Not Start
Starter Motor Operates But
Engine Does Not Start
Check the following items:
● Check the correct engine starting sequence.
2 P. 218
● Check that there is gasoline in the fuel tank.
● Check if the PGM-FI malfunction indicator
lamp (MIL) is on.
u If the indicator lamp is on, contact your
dealer as soon as possible.
Starter Motor Does Not
Operate
Check the following items:
● Check the correct engine starting sequence.
2 P. 218
● Make sure engine stop switch is in the
(Run) position.
2 P. 115
● Check for a blown fuse. 2 P. 334
● Check for a loose battery connection
(2 P. 267) or battery terminal corrosion
(
2 P. 256).
● Check the condition of the battery. 2 P. 333
If the problem continues, have your vehicle
inspected by your dealer.

Honda Africa Twin CRF1100D 2022 Specifications

General

Engine Type	Liquid-cooled 4-stroke 8-valve parallel twin with 270° crank and Uni-cam
Displacement	1, 084 cc
Bore x Stroke	92 mm x 81.5 mm
Compression Ratio	10.1:1
Front Tire	90/90-21
Wheelbase	1, 575 mm
Lighting	Full LED Lighting
Transmission	6-speed manual
Fuel System	Electronic fuel injection
Fuel Tank Capacity	24.8 liters
Front Suspension	Showa 45mm inverted telescopic fork with adjustable preload, compression and rebound damping
Rear Suspension	Pro-Link with Showa gas-charged damper, adjustable preload and rebound damping
Front Brakes	Twin 310 mm discs, 4-piston calipers
Rear Brakes	Single 256 mm disc, 1-piston caliper
Rear Tire	150/70R18
Seat Height	850 mm
Instruments	6.5-inch TFT
Max Power Output	75 kW (101 hp) @ 7, 600 rpm
Torque	105 Nm (77 lb-ft) @ 6, 400 rpm
Curb Weight	236 kg (520 lbs)
