Honda CB160 - Exhaust Pipe and Muffier

4. 8 EXHAUST PIPE AND MUFFLER
2. Measurement of the outside diameter of the stand
mounling bolt.
Standard value
Correction limit
Outside
1 0
So 1.25 2nd doss
diameter
by JIS
3. Measurement of the stand mounting hole.
Standard value Correction limit
Bore
14.4
to 14.6 mm
1.57" to .58"1
D. Assembly
l . Tighten the main stand with the l O mm bolt and
nut.
2. The rear brake cable assembly is the reverse of
disassembly.
3. Evenly tighten the muffler with four 8 X 25 hex
bolts to the underside of the crankcase. (Refer
to Fig. 4. 48)
4. 8 Exhaust pipe and muffler
INNE~ PIPEA
INNER PIPE GUIDE A lt;NER PIPE B
Fig. 4. 48 Even tightening of muffler steps
INNER PIPE C INMER, PIPED
Fig. 4. 49 Sectional view of muffler
A. Construction of the exhaust pipe and muffler
The exhaust pipe passes the exhaust gas from the
cylinder head
to the muffler ; if bent, the horsepower
is reduced. For exhaust gas the passage is throttled
in the muffler and noise is reduced. In addition,
noise
is diffused by the diffuser pipe which also
reduces noise.
8. Disassembly
l. Tools required for disassembly and assembly of
the exhaust pipe and muffler. (Refer to Fig. 4. 50)
Fig. 4. 50 Tools required for disassembly and assembly
of the 8){haust pipe and muffler
67
