Fig. 24
F ig. 25
/~\\ j' . F ig . 26
~:;.;.
~~
Fi g. 27
,"
Disa ssembly
6"}{1I nut
5.
Com chain
52
Assembly
Tightening torque
2.1 kgm 115ft. Ibl
Fitting direction of clip;
fit the jOint to the
direction of revolu~
tion of the c ronk
Precaution
Tools
steering top COne race
box wrench
In case of disassembly
and fllting of the
com
chain, be ca r e~
ful no t to drop clip
into the cylinder
head.
Pliers
Tie a wire at the end
of chain to prevent
chain from dropping
into the cylinder.
Disassembly
6.
Cylinder head
Assembly
Combination process
Ci) Coincide "T" punch
mark on the dynamo
rotor with the arrow
mark On the starter .
GD Coincide punch
mark
on the ri ght
tooth surface of the
cam
sprocket COm-
plete wi th the center
line of th e cylinder
head, and combine
sprocket of cronk
shaft by chain.
Beforehand, valve
ro cker arm, com
shaft
and valve
should be subassem-
bled.
Pay atten t ion to "0
ring and gasket.
Precaution
Toois
Plastic hamm er
53
t
Fi g. 28
Fig. 29
Fi g_ 30
