Honda CBR1000RR Fireblade 2021 User Manual

Adjusting the ÖHLINS Smart EC
System
CBR1000SP
This model is equipped with the ÖHLINS
Smart EC system.
This system consists of front and rear
suspension and Suspension Control Unit
(SCU).
This system provides the pre-programmed
damping characteristics optimized for
different situation to the front and rear
suspension.
SCU constantly determines riding conditions
from vehicle information. As a result, this
system provides the optimum rebound and
compression damping characteristics.
The system continually adjusts compression
and rebound damping levels according to
the riding situation.
You can adjusts the front and rear
suspension preload manually.
ÖHLINS Smart EC is a trademark of ÖHLINS RACING AB, Sweden.
20200219171806_31MKR6000_enu_BOOK Page 178 Wednesday, February 19 2020 17:28:26 JST
Other Adjustments u Adjusting the ÖHLINS Smart EC System
Maintenance
175
Continued

Honda CBR1000RR Fireblade 2021 Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Bore x Stroke	81 mm x 48.5 mm
Compression Ratio	13.0:1
Transmission	6-speed manual
Curb Weight	201 kg (443 lbs)
Displacement	999cc
Max Power Output	160 kW (214 hp) @ 14, 500 rpm
Max Torque	113 Nm (83 lb-ft) @ 12, 500 rpm
Fuel System	PGM-FI
Front Suspension	43mm Showa Big Piston Fork
Front Brakes	Dual 330mm discs with 4-piston calipers
Rear Brakes	Single 220mm disc with single-piston caliper
Front Tire	120/70 ZR17
Seat Height	830 mm
Fuel Capacity	16.1 liters
Rear Suspension	Pro-Link with gas-charged HMAS damper
Rear Tire	200/55 ZR17
