Honda CBR1000RR Fireblade 2021 User Manual

Activating the Electrical System in an Emergency
The mechanical key and ID tag can be used
to activate the electrical system when the
electric system cannot be turned on because
the Honda SMART Key battery becomes
weak or dead.
#
Set up to ID number input mode
1. Remove the front seat using a 5 mm Hex
wrench provided in the tool kit.
u To access the tool kit, remove the rear
seat. 2 P. 150
2. Remove the fuse box cover. 2 P. 202
3. Pull out the SMART ECU fuse with the
fuse puller and wait about 2 minutes
before insert the SMART ECU fuse again.
4. Push and hold the ignition ON switch for
more than 4 seconds.
u The steering lock indicator comes on
and the system enters the ID number
input mode.
5. Check the ID number on the ID tag.
20200219171806_31MKR6000_enu_BOOK Page 197 Wednesday, February 19 2020 17:28:26 JST
Troubleshooting
194
SMART ECU fuse
ID number

Honda CBR1000RR Fireblade 2021 Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Bore x Stroke	81 mm x 48.5 mm
Compression Ratio	13.0:1
Transmission	6-speed manual
Curb Weight	201 kg (443 lbs)
Displacement	999cc
Max Power Output	160 kW (214 hp) @ 14, 500 rpm
Max Torque	113 Nm (83 lb-ft) @ 12, 500 rpm
Fuel System	PGM-FI
Front Suspension	43mm Showa Big Piston Fork
Front Brakes	Dual 330mm discs with 4-piston calipers
Rear Brakes	Single 220mm disc with single-piston caliper
Front Tire	120/70 ZR17
Seat Height	830 mm
Fuel Capacity	16.1 liters
Rear Suspension	Pro-Link with gas-charged HMAS damper
Rear Tire	200/55 ZR17
