Honda CTX700A - Clip

Removing & Installing Body Components u Clip
68
Maintenance
Clip
The clip must be removed to remove the
right under cowl lid and centre lower cowl.
❙
Removal
1. Loosen the pin by a Phillips screwdriver.
2. Pull the clip out of the hole.
❙
Installation
1. Insert the clip into the hole.
2. Push the pin in.
!a
!b
!a !b
