Honda EU65is Service Manual

6-1
6. FRONT COVER/INVERTER UNIT/
CONTROL PANEL
1. FRONT COVER.................................... 6-1
2. INVERTER UNIT.................................. 6-2
3. CONTROL PANEL ............................... 6-5
1. FRONT COVER
a. REMOVAL/INSTALLATION
Remove the handle (P. 16-1).
[4]
FRONT COVER
SEAL A
[3]
FRONT COVER
SEAL C
[5]
FRONT COVER
COLLAR (2)
[8]
SPRING NUT
[9]
BATTERY MAINTENANCE
COVER
[7]
6 mm CAP NUT (2)
8.5 N·m (0.9 kgf·m,
6.3 lbf·ft)
[6] FRONT COVER
INSTALLATION:
Align the groove of the front vover with the rib of
the front frame
[6]-1
FRONT
COVER
[6]-2 RIB
[6]-4 GROOVE
[6]-3
FRONT FRAME
[2]
6 x 26 mm SPECIAL
BOLT (2)
8.5 N·m (0.9 kgf·m,
6.3 lbf·ft)
[1]
BATTERY
MAINTENANCE
COVER BOLT
2.3 N
.
m (0.2 kgf
.
m,
1.7 lbf
.
ft)
cap.06EU65is6500is(Eu).qxd07.12.174:51PMページ6-1

Honda EU65is Specifications

General

Model	EU65is
Type	Inverter
Maximum AC Output	6500W
Rated AC Output	5500W
Noise Level at 1/4 Load	52 dB(A)
Noise Level at Rated Load	60 dB(A)
Starter System	Electric
Engine Displacement	389 cc
i-Monitor	Yes
AVR	Yes
DC Output	12V, 8.3A
Engine	Honda GX390
Run Time at Rated Load	5.1 hours
AC Output	120/240V
Fuel Type	Gasoline
