Honda GX240 Technical Manual

GX240 • GX270 • GX340 • GX390 (UT2/RT2) Technical Manual
© 2010 American Honda Motor Co., Inc — All Rights Reserved 15
1A/3A Charging System
LED
OIL_ALT
EXT ( - )
EXT ( + )
ST
EXT ( + )
EXT ( - )
BAT
( Bl/W )
( W )
R
Bl
Y
( Y )
( W )
( W ) ( W )
( W ) ( W )
( Gr )
( Bl/W )
( R )
( Bl )
( W )
W
( R )
( Bl )
Gr
( R )
( Bl )
C6
C4
C5
C2
C1
T1
T2
T3
1
4 3 1 2
2 1
C3
C7
2
CONTROL BOX
COMBINATION
SWITCH
SILICON
RECTIFIER
CIRCUIT
PROTECTOR
MAIN FUSE
STARTER MOTOR BATTERY CHARGE
COIL
IGNITION
COIL
SPARK
PLUG
OIL LEVEL
SWITCH
Bl Black
Y Yellow
Bu Blue
G Green
R Red
W White
Br Brown
O Orange
Lb Light blue
Lg Light green
P Pink
Gr Gray
TWO COLORED WIRE (EXAMPLE:YELLOW/RED)
EXT ( + ) EXT ( - ) ST BAT
OFF
ON
START
COMBINATION
SWITCH

Honda GX240 Specifications

General

Compression Ratio	8.2:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Displacement	242 cm³
Net Power Output	3, 600 rpm
Net Torque	2, 500 rpm
Fuel Tank Capacity	5.3 liters
Oil Capacity	1.1 liters
Starting System	Recoil starter
Dry Weight	25 kg (55 lbs)
Bore x Stroke	73.0 x 58.0 mm (2.9 x 2.3 in)
