Honda GX240 Technical Manual

GX240 • GX270 • GX340 • GX390 (UT2/RT2) Technical Manual
14 © 2010 American Honda Motor Co., Inc — All Rights Reserved
10A Charging System
LED
OIL_ALT
EXT ( - )
EXT ( + )
ST
EXT ( + )
EXT ( - )
BAT
( Bl/W )
( W )
R
W W Gr W
Bl
Gr Gr
Bl/Y
W
Bl
W/Bu
Bl
Y
Y
Bl/W
( Bl )
R
Bl
W
W W
(W)
R
Bl
(W)
R
Bl
Bl
3
C10
C2
C1
T2
T3
1
4312
C3
C11
C4T1
T4
CONTROL BOX
COMBINATION
SWITCH
STARTER MOTORBATTERY
REGULATOR/
RECTIFIER
IGNITION
COIL
SPARK
PLUG
OIL LEVEL
SWITCH
Bl Black
Y Yellow
Bu Blue
G Green
RRed
W White
Br Brown
O Orange
Lb Light blue
Lg Light green
P Pink
Gr Gray
TWO COLORED WIRE (EXAMPLE:YELLOW/RED)
EXT ( + ) EXT ( - ) ST BAT
OFF
ON
START
461235
COMBINATION
SWITCH
MAIN FUSE
4
12
Gr W
Gr W
CHARGE COIL
FLYWHEEL

Honda GX240 Specifications

General

Compression Ratio	8.2:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Displacement	242 cm³
Net Power Output	3, 600 rpm
Net Torque	2, 500 rpm
Fuel Tank Capacity	5.3 liters
Oil Capacity	1.1 liters
Starting System	Recoil starter
Dry Weight	25 kg (55 lbs)
Bore x Stroke	73.0 x 58.0 mm (2.9 x 2.3 in)
