Honda GX240 Technical Manual

GX240 • GX270 • GX340 • GX390 (UT2/RT2) Technical Manual
© 2010 American Honda Motor Co., Inc — All Rights Reserved 41
Engine Oil Level Check
Place the engine on a level surface.
Remove the oil filler cap (1), and wipe the oil level gauge (2) clean.
Insert the oil filler cap without screwing it into the oil filler neck (3).
Remove the oil filler cap and check oil level shown on the oil level gauge.
If the oil level is low, fill with recommended oil to the upper level (4) of the oil
filler neck.
SAE 10W - 30 is recommended for general use. Other viscosities shown in
the chart may be used when the average temperature in your area is within
the recommended range.
Tighten the oil filler cap securely.
RECOMMENDED OIL:
SAE 10W-30 API service classification SJ or later
(1)
(3)
(2)
(4)
(2)
(3)
(1)
SAE VISCOSITY GRADES
AMBIENT TEMPERATURE

Honda GX240 Specifications

General

Compression Ratio	8.2:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Ignition System	Transistorized magneto ignition
Fuel System	Carburetor
Lubrication System	Forced splash
Displacement	242 cm³
Net Power Output	3, 600 rpm
Net Torque	2, 500 rpm
Fuel Tank Capacity	5.3 liters
Oil Capacity	1.1 liters
Starting System	Recoil starter
Dry Weight	25 kg (55 lbs)
Bore x Stroke	73.0 x 58.0 mm (2.9 x 2.3 in)
