Honda HRN216VYC User Manual

7-4
RECOIL STARTER HRN216
4. RECOIL STARTER INSPECTION
1. Remove the recoil starter (P. 7 - 2 ).
2. Check the operation of the ratchets by pulling the starter rope
out several times.
3. Check the tabs on the flywheel for damage.
5. RECOIL STARTER ROPE REPLACEMENT
1. Remove the recoil starter (P. 7 - 2 ).
2. Pull the starter rope until the starter rope is pulled out fully.
See page 7-6
if the rope is broken.
RATCHETS
TABS
STARTER
ROPE

Honda HRN216VYC Specifications

General

Engine Type	Honda GCV170
Cutting Width	21 inches
Deck Material	Steel
Weight	84 lbs
Starting System	Recoil
Mulching Capability	Yes
Bagging Capability	Yes
Discharge	Rear
Side Discharge Capability	Yes
Cutting Height Adjustment	Lever
Cutting Height	1-4 inches
Drive Type	Variable Speed
