Honda NHX110 User Manual

GENERAL INFORMATION
1-14
ELECTRIC STARTER
LIGHTS/METERS/SWITCHES
OTHERS
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Starter motor case screw 3 4 2 (0.20, 1.5)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Ignition switch protector socket
bolt
1 6 8.5 (0.87, 6.3) One way bolt; replace with a
new one.
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Brake shoe anchor pin nut
(When using the stake nut) 1 8 20(2.0, 15)
(When using the normal nut) 1 8 18(1.8, 13) Stake after tightening.
Centerstand spring bolt 1 8 22 (2.2, 16)
Reflector mounting nut 1 5 1.7 (0.17, 1.3) U-nut
Throttle cable lock nut (Throttle
housing side)
1 10 1.5 (0.15, 1.1)
Left crankcase cover plate screw 3 4 3 (0.31, 2.2)
Crankcase breather hose joint
plate screw
1 4 3 (0.31, 2.2)
