FRONT WHEEL/SUSPENSION/STEERING
15-3
SERVICE INFORMATION
GENERAL
• This section covers the front wheel, fork, handlebar and steering stem.
• When servicing the front wheel, fork or steering stem, support the scooter using a jack or other support.
• A contaminated brake disc or pad reduces stopping power. Discard contaminated pads and clean a contaminated disc
with high quality brake degreasing agent.
• After the front wheel installation, check the brake operation by applying the brake lever.
• For brake system service, refer to the following:
– Brake fluid replacement/air bleeding (page 17-5)
– Brake pad/disc (page 17-8)
– Front brake master cylinder (page 17-11)
– Brake equalizer (page 17-16)
– Front brake caliper (page 17-20)
• Use only tires marked "TUBELESS" and tubeless valves on rim marked "TUBELESS TIRE APPLICABLE".
• When using the pin spanner, use a 25 cm (10 in) long deflecting beam type torque wrench. The pin spanner increases
the torque wrench’s leverage, so the torque wrench reading will be less than the torque actually applied to the steering
stem adjusting nut. The specification given on this page is actual torque applied to the steering stem adjusting nut, not
the reading on the torque wrench when used with the pin spanner. The procedure later in the text gives the actual and
indicated torque.
SPECIFICATIONS
Unit: mm (in)
TORQUE VALUES
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth – To the indicator
Cold tire
pressure
Driver only 175 kPa (1.75 kgf/cm
2
, 25 psi) –
Driver and passenger 175 kPa (1.75 kgf/cm
2
, 25 psi) –
Axle runout – 0.2 (0.01)
Wheel rim
runout
Radial – 2.0 (0.08)
Axial – 2.0 (0.08)
Fork Spring free length 218.0 (8.58) 213.6 (8.41)
Pipe runout – 0.2 (0.01)
Recommended fluid Fork fluid –
Fluid level 52 (2.0) –
Fluid capacity 89.0 ± 1.0 cm
3
(3.01 ± 0.03 US oz,
3.13 ± 0.04 Imp oz)
–
Front brake disc socket bolt 42 N·m (4.3 kgf·m, 31 lbf·ft) ALOC bolt; replace with new ones
Front axle nut 59 N·m (6.0 kgf·m, 44 lbf·ft) U-nut
Fork socket bolt 20 N·m (2.0 kgf·m, 15 lbf·ft) Apply locking agent to the threads
Fork pinch bolt 49 N·m (5.0 kgf·m, 36 lbf·ft)
Fork cap bolt 23 N·m (2.3 kgf·m, 17 lbf·ft)
Handlebar post nut 33 N·m (3.4 kgf·m, 24 lbf·ft) See page 15-22
Brake master cylinder holder bolt 12 N·m (1.2 kgf·m, 9 lbf·ft)
Steering stem lock nut See page 15-26
Steering stem adjusting nut See page 15-26
