CRANKCASE/CRANKSHAFT
14-12
Install the plunger, spring, set plate and tighten the
bolt.
Refer to service information (page 14-3) for installa-
tion of parts removed to perform crankcase service.
SPRING
PLUNGER
BOLT
SET PLATE
