BRAKE SYSTEM
17-21
Remove the pin boots and pad spring from the
brake caliper.
Place a shop towel over the piston.
Position the caliper body with the piston down and
apply small squirts of air pressure to the fluid inlet
to remove the pistons.
Be careful not to
damage the piston
sliding surface.
Push the dust seals and piston seals in and lift them
out.
Clean the seal grooves, caliper cylinder and piston
with brake fluid.
INSPECTION
Check the caliper cylinder for scoring, scratches or
damage.
Measure the caliper cylinder I.D.
Do not use high
pressure air or bring
the nozzle too close
to the inlet.
SERVICE LIMIT: 27.060 mm (1.0654 in)
