5.
Replace the O-ring and apply a thin coat
of engine oil to the new O-ring before
installing it.
6.
Install the spring and the clutch oil filter
cover.
7.
Install the clutch oil filter cover bolts and
tighten.
8.
Apply a thin coat of engine oil to the
rubber seal of a new engine oil filter.
2 P. 89
9.
Install a new engine oil filter and tighten.
Torque: 19 lbf·ft (26 N·m, 2.7 kgf·m)
10.
Install a new sealing washer onto the
drain bolt. Tighten the drain bolt.
Torque: 22 lbf·ft (30 N·m, 3.1 kgf·m)
11.
Fill the crankcase with the recommended
oil (2 P. 67, 2 P. 152) and install the oil fill
cap/dipstick.
Required oil
When changing oil, engine oil filter
& clutch oil filter:
3.6 US qt (3.4 L)
12.
Check the oil level. 2 P. 86
13.
Check that there are no oil leaks.
14.
Install the right under cowl.
Engine Oil u Changing Clutch Oil Filter
Maintenance
91
