Honda PCX 160 User Manual

Coolant
Checking the Coolant
Check the coolant level in the reserve tank
while the engine is cold.
1. Place your vehicle on its centre stand on a
firm, level surface.
2. Check that the coolant level is between
the UPPER level and LOWER level marks
on the reserve tank.
If the coolant level is dropping noticeably or
the reserve tank is empty, you likely have a
serious leak. Have your vehicle inspected by
your dealer.
Adding Coolant
If the coolant level is below the LOWER level
mark, add the recommended coolant
(2 P. 84) until the level reaches the UPPER
level mark.
Add fluid only from the reserve tank cap and
do not remove the radiator cap.
1. Pull the floor mat off.
2. Remove the reserve tank lid by inserting a
flat head screwdriver covered with a
protective cloth into the slit on the right
side floor.
20220603164939_32K1ZR000_eng_BOOK Page 97 Friday, June 03 2022 16:52:56 JST
Maintenance
94
UPPER level mark
LOWER level mark
Reserve tank

Honda PCX 160 Specifications

General

Displacement	156.9 cc
Bore x Stroke	60.0 mm x 55.5 mm
Compression Ratio	12.0:1
Starting System	Electric
Front Suspension	Telescopic Fork
Front Brake	Hydraulic Disc
Length	1, 935 mm
Width	740 mm
Height	1, 105 mm
Wheelbase	1, 315 mm
Seat Height	764 mm
Fuel Capacity	8.1 liters
Max Power	11.8 kW (16.0 PS) @ 8, 500 rpm
Fuel System	PGM-FI
Ignition System	Full Transistorized
Transmission	V-Matic
Rear Tire	130/70-13M/C
Front Tire	110/70-14 M/C 50P
