Honda PCX 160 User Manual

Specifications
■ Main Components
Overall length 1,935 mm (76.2 in)
Overall width 742 mm (29.2 in)
Overall height 1,108 mm (43.6 in)
Wheelbase 1,313 mm (51.7 in)
Minimum ground
clearance
134 mm (5.3 in)
Caster angle 26º 30’
Trail 79 mm (3.1 in)
Curb weight 132 kg (291 lb)
Maximum weight
capacity
*1
180 kg (397 lb)
Maximum luggage
weight
*2
Centre compartment 10 kg (22 lb)
Front box 1.0 kg (2.2 lb)
Rear carrier 5 kg (11 lb)
*1 : Including rider, passenger, all luggage, and accessories.
*2 : Includes the weight of the luggage and added accessories.
Passenger capacity Rider and 1 passenger
Minimum turning radius 1.90 m (6.2 ft)
Displacement
156.9 cm
3
(9.573 cu-in)
Bore x stroke
60.000 x 55.502 mm (2.3622 x 2.1851
in)
Compression ratio 12.0:1
Fuel
Unleaded petrol
Recommended: 91 RON or higher
Fuels containing alcohol ETHANOL up to 10 % by volume
Tank capacity 8.0 L (2.11
US gal, 1.76 Imp gal)
Battery
DTZ6
12 V-5 Ah (10 HR)
Primary reduction V-Matic (2.52:1-0.81:1)
Final reduction 9.589
20220603164939_32K1ZR000_eng_BOOK Page 141 Friday, June 03 2022 16:52:56 JST
Specifications
138

Honda PCX 160 Specifications

General

Displacement	156.9 cc
Bore x Stroke	60.0 mm x 55.5 mm
Compression Ratio	12.0:1
Starting System	Electric
Front Suspension	Telescopic Fork
Front Brake	Hydraulic Disc
Length	1, 935 mm
Width	740 mm
Height	1, 105 mm
Wheelbase	1, 315 mm
Seat Height	764 mm
Fuel Capacity	8.1 liters
Max Power	11.8 kW (16.0 PS) @ 8, 500 rpm
Fuel System	PGM-FI
Ignition System	Full Transistorized
Transmission	V-Matic
Rear Tire	130/70-13M/C
Front Tire	110/70-14 M/C 50P
