Check the fluid level with the
transmission at normal operating
temperature and the vehicle sitting
on level ground.
To check the transmission fluid level,
remove the two bolts, then pull down
the left part of the under cover.
Remove the check bolt and look for
transmission fluid coming out of the
bolt hole. If a small amount of fluid
drips out of the bolt hole, reinstall
the check bolt. Tighten it to:
If no fluid comes out, remove the
filler bolt. Slowly add genuine Honda
Manual Transmission Fluid (MTF)
until it starts to run out of the check
bolt hole. Let the fluid run out until it
stops, then reinstall the check bolt
and the filler bolt. Tighten them to:
(Check bolt)
See previous column.
(Filler bolt)
6-speed Manual Transmission
Transmission Fluid
Maintenance
2.4 engine model
440
CHECK BOLT
BOLT UNDER COVER
FILLER BOLT
BOLT
39 49 N·m (4.0 5.0 kgf·m , 29
36 lbf·ft)
9.8 14 N·m (1.0 1.4 kgf·m , 7
10 lbf·ft)
